Voice Alarm Router EVAC-8500RT

EN54-16 8 Zone Voice Alarm Router EVAC-8500RT.

EVAC-8500RT is EN54-16 certified 8 zone voice alarm router, which is used for zone expansion by working with voice alarm controller EVAC-8500. The voice alarm router is built-in 500W amplifier, voice alarm slave controller, 8 zone paging controller, speaker line monitoring and amplifier changeover.

Introducing the EN54-16 8 Zone Voice Alarm Router EVAC-8500RT, a state-of-the-art solution designed to enhance public safety through efficient voice alarm and evacuation management. This advanced device integrates multiple functionalities, including zone paging control, signal line monitoring, amplifier changeover, speaker line supervision, and fire alarm interfacing, making it an essential component for comprehensive public address and voice alarm systems.

Product Overview

The EVAC-8500RT is engineered to expand existing voice alarm systems by providing eight additional zones, each with a rated power output of 500W. It operates seamlessly with the master controller EVAC-8500, ensuring synchronized control and monitoring across all zones. The device is EN54-16 certified, adhering to stringent European standards for voice alarm control and indicating equipment, thereby guaranteeing reliability and compliance in critical situations.

Key Features and Specifications

Feature	Description
Certification	EN54-16 certified (Certification No. I/ISEETC.000620190305)
Integrated Functions	Combines voice alarm routing, zone paging control, signal line monitoring, amplifier changeover, speaker line supervision, power supply monitoring, and fire alarm interfacing
Zone Expansion	Provides 8 additional zones with a total power output of 500W
DSP Technology	Utilizes advanced Digital Signal Processing for high-fidelity audio performance and superior signal processing during announcements and evacuations
Compatibility	Designed to work in conjunction with the master controller EVAC-8500
Supervision Capabilities	Monitors all main signal lines, speaker lines, and power supplies to ensure system integrity
Amplifier Changeover	Features automatic amplifier changeover to maintain uninterrupted operation in case of amplifier failure
Fire Alarm Interface	Equipped with interfaces for seamless integration with fire alarm systems
User-Friendly Configuration	Pre-set configurations via supplied software, allowing customization of microphone numbers, zone assignments, speaker monitoring, fire alarm modes, and more
Compliance	Meets Construction Products Regulation (EU) No 305/2011: EN54-16:2008 standards for Voice Alarm Control and Indicating Equipment

Functional Advantages

Enhanced Safety: The EVAC-8500RT ensures clear and effective communication during emergencies, facilitating orderly evacuations and reducing panic.
Scalability: Its ability to add eight zones allows for flexible expansion of existing systems to accommodate larger or more complex facilities.
Reliability: Continuous supervision of all critical components and automatic amplifier changeover guarantee system functionality even in fault conditions.
High-Quality Audio: Advanced DSP technology delivers superior audio clarity for both announcements and alarm signals.
Compliance: Adherence to EN54-16 standards ensures the system meets international safety regulations, providing peace of mind to facility managers and occupants.

Applications

The EVAC-8500RT is ideal for a wide range of applications, including:

Public Buildings: Airports, train stations, shopping centers, and hotels requiring efficient evacuation systems.
Educational Institutions: Schools and universities needing reliable voice alarm systems for student and staff safety.
Healthcare Facilities: Hospitals and clinics where clear communication is critical during emergencies.
Industrial Complexes: Factories and warehouses requiring robust alarm systems to manage potential hazards.

Title and Description

Title: EN54-16 8 Zone Voice Alarm Router EVAC-8500RT – Advanced Voice Alarm System for Enhanced Public Safety

Description: Discover the EVAC-8500RT, an EN54-16 certified 8 zone voice alarm router designed for seamless integration into public address systems. With 500W output per zone, advanced DSP technology, and comprehensive supervision features, it ensures reliable and high-quality emergency communication across various applications.

Conclusion

The EN54-16 8 Zone Voice Alarm Router EVAC-8500RT stands as a pivotal component in modern voice alarm systems, offering unparalleled functionality, reliability, and compliance with international safety standards. Its integration of multiple essential features into a single device simplifies system architecture and enhances overall performance, making it an indispensable choice for facilities aiming to bolster their emergency communication capabilities.
